Custom Solutions
Drivers, Controls, Software & Apps
Engineered, Designed & Manufactured in Weeks — Not Years!
CUSTOMIZED For Your Equipment
Treadmill Driver for Antigravity applications
ESI’s antigravity driver control personalizes exercise and rehabilitation. This innovative system allows the user to fine-tune gravitational resistance to customize their ideal workouts, whether they’re recovering from an injury, enhancing athletic performance, or simply pursuing a more comfortable, effective exercise routine.
Tech Specs
- 4 HP belt motor PWM drive with digital speed feedback
- Incline AC motor drive with analog position feedback
- 1 amp 12 volt console power supply
- Medical grade isolation
- Vertical mount bracket and heat sink
Rehabilitation Treadmill Motor control Drive
The motor control board regulates a treadmill’s speed, incline, and overall functionality. ESI’s Rehabilitation Treadmill Drive powers gait trainer treadmills used to rehabilitate and restore normal gaits in balance compromised patients. This system provides visual feedback for stride length, speed, and symmetry, with audible feedback for training.
Tech Specs
- 3 HP reversible belt motor PWM drive with high resolution digital speed feedback
- Braking system to allow operation at high inclines
- Incline AC motor drive with analog position feedback
- 32-bit ARM CPU to control all functions in real time
- High speed serial communication console link for control and data
- Medical grade isolation
- Four point strain gauge monitoring system for foot plants
- Vertical mount extruded aluminum heat sink and mounting bracket
Balance control
ESI’s Balance System Drive powers the Biodex Balance System HD, a static and dynamic balance testing and training system designed for rehabilitation. Sensors monitor the patient’s movements in real time, and the electronic control system provides immediate feedback and adjusts the machine’s settings to accommodate the patient’s needs. The system offers 12 levels of difficulty, with exercises and tests that provide measurable results for assessment.
Tech Specs
- 12 volt high power, reversible platform DC motor drive
- Analog feedback for platform position, and overcurrent control
- Analog 2 axis tilt sensors with 12-bit A/D precision
- AC input switching for 120V and 240V operation
- Medical grade isolation
- Fused printer power connector
Body Composition Analyzer Software & Tablet
ESI’s Body Composition Analyzer Tablet powers the complete analysis system, which measures weight, body fat, and blood pressure, and provides guidelines for optimal health and well-being. User-friendly prompts and video instructions guide users to enter their information, then summarizes their subsequent measurements into a printable report that can be uploaded to an app or website.
Tech Specs
- Frameless 10” Android tablet with 1280 x 800 TFT and touch screen
- Android based application with Wi-Fi connectivity
- Wi-Fi print drivers for network printing
- USB connection and drivers for connection to measuring unit
- QR code data output for linking with mobile app
- Multiple language support
Heated composite dispenser control
ESI’s Heated Composite Dispenser Control optimizes the Compex HD Composite Curing System. The adaptive temperature control with thermistor feedback allows dentists to adjust resin curing intensity to each composite’s unique requirements, ensuring a more effective and efficient curing process.
Tech Specs
- One-touch button and display unit for operation and charging
- High power PWM heater unit
- Adaptive temperature control with thermistor feedback
- 32-bit embedded ARM CPU
- Lithium-ion battery system with regulated charger
- USB connection for charging and firmware update
